The Serveredge basic PDUs are the most efficient way to power protect your rack mount equipments. Serveredge PDUs are built to both Australian & International standards and requirements, so that your equipment can deliver the most optimum performance while using minimum of your valuable rack space. The PDUs have a Metal Alloy casing which makes them durable for rack mount use in vertical applications.
PRODUCT FEATURES
• Output Ports: (20) IEC C13, (4) IEC C19
• Overload Protection
• Supplied with a PDU-BKT Vertical Mounting Bracket Kit
• Vertical Mounting capabilities saves valuable rack space.
• Input Power Source: IEC C20, 16A
• Power Indicator Light.
* Warranty: 2 Years Manufacturers Warranty
PRODUCT SPECIFICATIONS
| Configuration | 0RU, Vertical |
| Colour | Black |
| Maximum Depth | 45mm |
| Maximum Height | 45mm |
| Maximum Width | 1053mm |
Output |
|
| Output | 20 x IEC C13, 4 x IEC C19 |
Input |
|
| Input | 1 x IEC C20 Input Plug |
| Cable-length | 2m |
| Maximum input current | 16A |
| Voltage | 240V |
Conformance and Compliance |
|
| EESS Conformity |
PACKAGING INCLUDES
| SEDG-24PV-C13C19-15A | 1 |
YOU'RE REVIEWING:
Basic 24 Port 0RU Vertical PDU, (20) IEC C13 Output, (4) IEC C19 Output (1) IEC C20 Input ,16A
