Serveredge 4-Port Desktop USB/PS2/VGA KVM Switch - Includes Cables


The Serveredge KD04UV, is a 4-Port KVM switch that allows access to four computers from one USB or PS/2 keyboard, mouse and a VGA monitor.


Serveredge 2-Port USB / DisplayPort Desktop KVM Switch With Audio & USB Hub2.0. Includes Cables.



* Support USB console
* 2 computers share 4 different USB peripherals ( KB + MS + USB 2.0 Devices)
* Support Audio (Speaker + Mic) function
* Supports hot plug and un-plug detection and link status-failure detection
* Unique Tracking System enable the USB devices to operate independently
* Front panel push buttons for easy computer selection
* Selectable Scan Time interval
* Buzzer sound for computer switching confirmation
* Hotkey functions allow easily computer access
* Supports keyboard and mouse plug-n-play
* Supports existing VESA and Consumer Electronics Association (CEA) standards
* Screw-free design ,streamlined form factor for new all digital desktop monitors
* All digital Direct Drive monitors connected with DisplayPort require no adjustment
* Complete interoperability
* Supports 7.1 Channel High Definition Audio
* No drivers needed; No software required
* Support Windows and Mac host systems
* Warranty : 1-year




Product Description

4-Port Desktop USB/PS2/VGA KVM Switch

Number Of Computers Controlled 4
Selection Method Push Button and Hot-Key (PS/2 and/or USB Keyboard)
LEDs Red for PC Selection
Green for PC On-Line ready
PC Connections 1 X HD-15(VGA). ( PS/2 or USB signal are combined with the VGA port )
Console Connections Keyboard 1 x 6 pin mini-DIN female (PS/2) or 1 x USB Type A female
  Mouse 1 x 6 pin mini-DIN female (PS/2) or 1 x USB Type A female
  Video 1 X HD-15(VGA)
Auto-Scan Interval From 5 to 250 Seconds
DDC, DDC2 monitor Yes (Max. Resolution: 2048x1536)@85Hz
Hot Swappable Yes
Operating systems supported Windows 98SE/ME/2000/XP/Vista/2003 Server/7/8/8.1, Linux, Mac OS9/OSX and Sun Micro System
Device drivers No Drivers Required
Power By PS/2 and/or USB or Power Adaptor (Optional)
Cable Length 1.8m
Dimensions (L×W×H) 215 x 88 x 45 mm
Unit Weight 650 g
Housing material Metal
Operating Temperature 32~ 122°F  (0~ 50°C)
Humidity 0%~80%RH
